CXH7-21P Type Panama Suez Canal Steering Light
- 12V/24V/220V, power 25W. With BAY15d lamp holder.
- Suitable for cables with outside diameter of 9mm.
- The shell is made of good quality stainless steel, The light shade is made of good quality Pyrex.
- “+”type ht hole, it can make the light beam much more focus.
CXH7-21P Type Panama Suez Canal Steering Light
The steering light, which is a kind of ship signal light, is applied to confirm the bow direction on the voyage and it is suitable for the recognition, in particular, Panama Suez Canal. The shell of the light is made of good quality stainless steel and has the feature of corrosion-resisting, shock resistance, etc. It has a“+” type ht hole and can make the light beam much more focused. The shade is made of good quality Pyrex with good light transmission. It can work under the environmental temperature of -30℃~55℃. It has a protection class of IP56. YSmarines can provide superior quality marine steering light, cheap price guaranteed.
Adopt standard:
1. Conform to THE INTERNATIONAL REGULATIONS FOR PREVENTING COLLISION AT SEA,1972 and GRADE ENTRY NORMS FOR STEEL SHIPS.
2. Conform to the standard of marine electric signal light’s technical condition GB/T 3028-1995.
Production authentication:
1. Approved by CCS (CHINA CLASSIFICATION SOCIETY) and ZY of China Fishery Inspection.
| Type | CXH7-21P |
| Voltage | 12V/24V/220V |
| Power | 25W |
| Lamp Holder | BAY15d |
| Visibility | 2n.m |
| Environmental temperature | -30℃~55℃ |
| Cable outside diameter | 9mm |
| Protection class | IP56 |
| Color | Blue |
| Weight | 1.2KG |
| Material | High-strength engineering plastic PA+GF, PC, Stainless Steel |
